Badar Aluminium is a reputable manufacturer and supplier located in Manama, Bahrain, with a specialization in top-notch Aluminium 1050 forgings. The company prides itself on precision engineering and a commitment to customer satisfaction, providing reliable forging solutions tailored to a variety of industrial needs. Renowned for crafting durable, corrosion-resistant, and lightweight components, Badar Aluminium caters to sectors like construction, electrical, automotive, and general engineering. Thanks to advanced manufacturing techniques, skilled professionals, and rigorous quality control, the company guarantees products that align with international standards. As a prominent Aluminium 1050 forgings manufacturer in Bahrain, Badar Aluminium consistently raises the bar in the industry.
The Aluminium 1050 forgings from Badar Aluminium are primarily composed of 99.5% pure aluminium, with only trace amounts of silicon, iron, copper, and other elements. This high-purity alloy boasts excellent corrosion resistance, remarkable thermal and electrical conductivity, and good ductility. Although it can’t be heat-treated, Aluminium 1050 can be strengthened through work hardening, offering great formability along with moderate strength. These mechanical properties make it perfect for applications that require lightweight, conductive, and easily fabricated components.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Badar Aluminium based in Manama, Bahrain is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Badar Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@badaraluminium.com
Badar Aluminium’s Aluminium 1050 forgings are utilized across a wide range of industries due to their impressive conductivity, corrosion resistance, and ease of fabrication. They’re commonly found in electrical systems for busbars, connectors, and conductive fittings. In the construction sector, they serve as architectural components, brackets, and structural elements. Their lightweight and conductive characteristics also make them ideal for automotive parts, cooling systems, and heat exchangers. Furthermore, these forgings are essential in food processing machinery, chemical handling equipment, and general engineering applications where purity and durability are crucial.
